Single Phase: 230V/50Hz,115V/60Hz
Insulation Class: F
| Product NO. | TGP600(inox,A,B)-7J | TGP800(inox,A,B)-7J | TGP1000(inox,A,B)-7J | TGP1200(inox,A,B)-7J |
| Power | 600W | 800W | 1000W | 1200W |
| V&Hz | 230V/50Hz, 115V/60Hz | 230V/50Hz, 115V/60Hz | 230V/50Hz, 115V/60Hz | 230V/50Hz, 115V/60Hz |
| Max.pump rate(L/H) | 3000 | 3200 | 3500 | 3800 |
| Max.height(m) | 35 | 40 | 44 | 48 |
| Max.depth(m) | 8 | 8 | 8 | 8 |
| Dia.of pipe | 1" | 1" | 1" | 1" |
| Cable | H07RN-F3G1.0m㎡ | H07RN-F3G1.0m㎡ | H07RN-F3G1.0m㎡ | H07RN-F3G1.0m㎡ |
| Length of cable(m) | 1.2 | 1.2 | 1.2 | 1.2 |
| QTY/20'CTN | 1500pcs | 1500pcs | 1500pcs | 1500pcs |
| QTY/40'CTN | 3100pcs | 3100pcs | 3100pcs | 3100pcs |
| QTY/40'(H)CTN | 3410pcs | 3410pcs | 3410pcs | 3410pcs |
